ALPHA ATS Series
ALPHA ATS Series
Feature
Westinghouse Alpha series ATS Dual Power is a cutting-edge, highly reliable automatic transfer switch designed to ensure seamless power supply transitions during power failures.
Wide range of ATS from 32A to 6300A with types suitable for various applications including ATS with separate dual Bypass switch, tested to UL-1008 & IEC 60947-6-1 international standards. ATS with Bypass system has unique feature where Bypass switch can work as ATS when selected (full redundancy).
Built in accordance with IEEE 446, 666, 241, 242 that is recommended of design for emergency and standby systems, PC Class and CSA C22.2. Committed to environmental safety, Westinghouse adheres to the RoHS Directive (EU 2015/863), ensuring restricted use of hazardous substances in electrical and electronic equipment.
ATS comply with NEC standards, including NEC 700 (emergency), NEC 701 (legally required), NEC 702 (optional standby), and NEC 708 (critical operational systems), the Westinghouse Dual Power is particularly suited for special occupancies such as healthcare facilities (NEC 517).
Alpha series ATS operate on solenoid operating, has Neutral overlap feature, controlled by microprocessor-based controller with soft touch button. Controllers have indication for status and in-built mimic display showing full data of the system status. Operation during power failure without any battery supply.
With smart, versatile features, Westinghouse Dual Power is ideal for critical applications in diverse fields such as electrical equipment, automation systems, power plant, telecommunications, petrochemicals, hospitals, data centers, and smart buildings. Its robust reliability makes it a preferred choice in sectors including coal, metallurgy, railways, and municipal engineering, providing secure, uninterrupted power across demanding environments. Available in both standard and custom configurations.
Rated Current: 32A- 6300A
Rated operating voltage: Upto 480Vac, 50/60Hz
Utilization Category: AC- 33
Withstand Short Time Rating: up to 100KA
Rated Conditional Short Circuit Current: 200KA
Impulse Withstand Voltage: 8KV
Rated Insulation Voltage: 1000V
Enclosure Ratings: IP42, IP54 or IP55, Avialble in NEMA 1/3/4.
Open Transition Transfer Switch
Closed Transition Transfer Switch
Delayed Transition Transfer Switch
Open Bypass Isolation Transfer Switch
Closed Bypass Isolation Transfer Switch
Neutral Overlapping configuration available in Transfer switch.
Compliance: IECEE CB Scheme IEC 60947-6-1: 2021 & UL 1008:2022/ NFPA 70, CSA C22.2 #178.1:2022
